| Camera | |
| Image Sensor | 1 / 2.7″CMOS |
| Image Size | 3840 × 2160 |
| Electronic Shutter | 1 s ~ 1 / 100000 s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.11 lux @F2.2, AGC ON; 0 lux with IR 0.032 lux @ F1.2, AGC ON; 0 lux with IR |
| 0 lux with LED / IR ON | |
| Lens | 2.8 mm @F2.0, (fixed lens), horizontal field of view: 112° |
| Lens Mount M12 | |
| Wide Dynamic Range | Digital WDR |
| BLC | Yes |
| HLC | Yes |
| Defog | Yes |
| Digital NR | 3D DNR |
| Angle Adjustment | Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360° |
| Image | |
| Video Compression | Main stream: H.265+ / H.265 / H.264 ; Sub stream: H.265+ / H.265 / H.264/MJPEG |
| H.265 Compression Standard | Main [email protected] High Tier |
| Resolution | 8MP ( 3840 2160 ), 6MP ( 3072 2048 ), 5MP ( 2592 1944 ), 4MP ( 2592 1520 ), 2MP ( 1920 1080 ),720P ( 1280 720 ), D1, CIF, 480 240 |
| Main Stream | 8MP / 6MP / 5MP / 4MP / 2MP ~ (1 20fps) |
| Sub Stream | D1/CIF 480 240 / × (1~20fps) |
| Bit Rate | 64 Kbps ~ 8 Mbps |
| Bit Rate Type | VBR / CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Interfaces | |
| Network | RJ45 |
| FullColor | Yes |
| Audio | 1CH built-in microphone |
| Storage | Built-in micro SD card slot; up to 128GB |
| Hardware Reset | Yes |
| Functions | |
| Remote Monitoring | WebBrowser/TVT NVMS2.0/NVR/mobile APP |
| Online Connection | Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS |
| Interface Protocol | ONVIF |
| Storage | Network remote storage |
| Smart Alarm | Motion detection |
| Intelligent Analytics | Region intrusion detection, video blur detection and line crossing detection |
| General Function | Watermark, IP address filtering, video mask, heartbeat, illegal login lock |
| PoE | Yes |
| IR Distance | 30m |
| Ingress Protection | IP67 |
